Summary:
The high precision solid densitometer is suitable for the determination of the density of all solid materials. Solid densitometer USES German HBM high-precision weighing sensor, no need to tie product water measuring device;
The density value can be measured instantaneously, with a variety of measurement methods such as
saturation measurement method, surface covering waterproof treatment method and high viscous medium liquid method. The measurement precision is high, the data is reliable, the densitometer of our company simplified the operation steps and the way, upgraded the application function of the software, has the same kind of products can not match the reliability, so that the application customer group is more extensive.
Applications:
Suitable for: rubber, plastic, powder metallurgy, wire and cable, PVC, hard alloy, knife grinding products, manufacturing, automobile parts, tungsten alloy parts, diamond, new material research laboratory, electrical appliances, sports equipment, tires, glass products, hard alloy, powder metallurgy, magnetic materials, seals, ceramics, sponge, EVA materials, foam materials, alloys, friction materials, New materials, battery materials.
Suitable for : basic material density research, high density product density detection, micro and small product density detection, quality and cost control, new material formulation research and development… And other fields of application. Covers the water absorption, non-water absorption of all solid material field.
Standards:
ASTM D792、 ASTM D297、 GB/T1033、GB/T2951、 GB/T3850、 GB/T533、 HG4-1468、 JIS K6268、 ISO 2781、ISO 1183、GB/T208、GB/T5163、GB/T 1933、GB/T4196、GB/T4123、GB/T5586、JB/T7780….etc.
Features:
Direct reading density and volume of solid, particles and floating body in any shape, which density> 1 or <1
With temperature compensation setting, and solution compensation setting function, more humane operation
The density measurement station in one injection molding, easy and fast to install, long life-time.
Use corrosion-resistant large error integrally molded sink design to reduce the buoyancy of the hanging bar line caused, but also easy to test a relatively large massive objects
With the lower and upper limit function, can determine the proportion qualified or not, equipped with a buzzer system.
Built-in battery, with configuration windshield, more suitable for field testing.
Configuration special wind dust cover, combination convenient, strong and durable
Including RS – 232 – c communication interface, convenient connection PC and printers, can choose and buy QL – P printers print quickly measuring data
Advantages:
With German imported sensors, better repeatability
Flip free measurement, and simpler operation
Waterproof membrane fuselage, protect the interior fuselage avoid ooze water.
PC material tank , abrasion resistant to fall off, corrosion resistant
5cm stainless steel suspension wire, no bending deformation, do not touch the sink with vertical lifting bar.
The percentage of material content of the main material in the measurement of the mixed material.
Specifications:
Model
NG-XF120
NG-XF200
NG-XF300
Max load weight
120g
200g
300g
Weight accuracy
0.001g
Density accuracy
0.0001 g/cm3
Test range
0.0001—99.9999g/cm3
Test materials range
Any shape with density ＞ or ＜ 1, solid mass, particle, floating body
Test time
6 seconds
Temperature compensation
Solution temperature can set to 0~49°C
