Summary:
Universal Halogen Moisture Meter is the most advanced new plastic fast moisture meter studied and in
light of crack, bubbling and shrinking caused by much moisture in raw materials in the control of
production, injection molding and moulding technology in current plastic industry, which has no moveable parts outside and needs not to set measuring sample and time. Germany advanced technology is introduced in the weighing system so as to avoid instability and easy aging of domestic magnetic sensor. The heating system applies halogen heat device with humane operation so that experimenters can operate it without special training.
Its date is shown and the measurement result is visible and accurate. Instant printing function can
be operated by a key; standard 232 interface and exclusive software can realize on-line operation;
data is collected, analyzed, stored and printed at real time. At present, it has been extensively
applied to produce various raw materials, semi-finished products and finished products in the plastic
industry; for example, polyethylene (PE), polypropylene (PP), polrvinyl chloride(PVC), polystyrene (PS)
ABS resin (acrylonitrile-butadiene-styrene copolymer), polyamide (PA)(called nylon usually), makrolo
(PC), polyformaldehyde (POM), modified polyphenylene oxide, thermoplasticity (PET), polyphenylene
sulfide (PPS), liquid crystal polymer LCP, polyether-ether-ketone (PEEL), polyether ketone (PEK),
polyether sulfone (PES), PETG, engineering plastics – polysulfone (PSF), particles, auxiliaries, master
batch, wooden plastic and wood flour and so on.
Features:
Exclusively used in the plastic industry
2. Full-automatic test mode
3. Exclusive software and micro-printer with standard configuration
4. Fast test before and after dehumidification of samples
5. Stand-by operation of particle and powder
6. High efficiency, fast speed;
Specifications:
Model
NG-MS31
NG-MS32
NG-MS35
NG-MS21
Max. weighing range
100g
100g
100g
100g
Reading accuracy
0.001g
0.002g
0.005g
0.01g
Readability of Moisture ( >10g)
0.01%
0.02%
0.05%
0.10%
Scope of Moisture Measurement
0.01~100%
Pan size
φ110 (mm)
Heat source
HALOGEN LAMP
Temperature heating range
RT~160ºC
Communication interface
standard RS232 interface
Heating time range
1-99min
Operation temperature
10ºC-30ºC
Relative humidity
≤80%RH
Power supply
220V±10%, 50HZ±1HZ
Net weight
3.3kg
