ASTM D5264 Printing and Paper Ink Rub Testing Machine, Ink Friction Decoloration Tester
Model
NG-605
MOQ
1 Set
Lead Time
3-15 Working Days
Country of Origin
China
Package
Standard Export Wooden Box
OEM & ODM
Support
描述
用户评论 (0)
描述
Application:
This machine is mainly used for testing the abrasion performance and decoloration rate of printing ink, printing box etc. Use standard load, reciprocating friction travel and speed to friction
surface of sample. To confirm the class of pollution of sample and standard friction paper, and the fluff or abrasion of the sample surface.
Principle:
The test specimen mounted on top of the rubber pad is rubbed against the receptor mounted to the weight. The test duration is determined by the number of strokes. The number of strokes desired is preset on the timer and the tester will shut off automatically when the desired number of strokes is completed.
Standard:
GB/T7706, GB7707, JIS K5701, ASTM D5264, TAPPI T830 etc.
Features:
LCD displays data, convenient and effective.
• Film keyboard switch; PVC operation panel;
Power failure memory;
Built-in standard rub panel
Mute-sounds design, even friction.
Specifications:
TECHNICAL SPECIFICATIONS
Display
LCD Screen Display
Friction Speed
43 times/min ( 21,43,85,106 times/min, adjustable)
Friction Area
155(L)mm×50(B)mm
Friction Stroke
60mm
Friction Times
0~999999 Times
Friction Load
2lb, 4lb
Specimen Size
220(L)mm×50(B)mm
ENVIRONMENT REQUIREMENT
Temperature
15℃-35℃
Relative Humidity
No more than 70%,no dewdrop
Power Supply
220V 50Hz
Configurations
Ink printing Sutherland Rub Tester Host, standard friction block
