描述
Diameter
Φ35mm
Precision
Iron φ0.4mm
Copper φ0.5mm
SUS φ0.8mm
Detecting Weight
300-400KG/Hr
Detection Method
Electromagnetic Wave Detection Technology
Alarm Mode
Sound and Light Alarm with auto rejection
Elimination time
0.3-5seconds ( adjustable)
Gas Consumption
0.4 Liters Per Separation
Gas Input Source
0.3~0.5MBar
Output Signal Terminal
Counting signal, Reject signal
Frame Material
Paint
Input voltage /power
Single-phase AC200V 50Hz/100W
Operating Temperature
-10~+50ºC
Dimensions of the main part
Length 300*Width 400* Height 440(mm)
The metal separator is used to detect and separate all metals, including ferrous and non-ferrous metals (such as copper, aluminum, stainless steel) mixed in the plastic material.This machine has the advantages of fast separation speed, high detection accuracy, and easy installation, etc. It is a necessary equipment for plastic industry.
Features:
1. Intelligent Detection- Turn on and start running, which is convenient and quick, and maintenance-free.
2. Reliable Performance- Special structural design, strong stability, effective to avoid interference caused by mechanical vibration.
3.Fast Auto Reject- Instead of the traditional manual detection, the removal speed is fast, the production efficiency is high, and the utilization rate of raw materials is greatly improved.
4.Maximum Detection Accuracy- Improve product quality, but also to some extent reduce the back-end equipment, such as injection molding machine, grinder maintenance costs and loss caused by shutdown maintenance.
5. Wide range of sensitivity adjustable- Bespoke solution
6. Endurable- 304 stainless steel, sanitary and clean.
7. Compact design- Easy to install and operate
