Application:
Food Security Metal Detector is mainly used for detecting the metal chips inside the nuts, rice, tea and wood processing industry etc. Besides it can also be used for the detection of metallic impurities in chemicals, rubber, plastics, textiles, leather, chemical fiber, toys as well
as for the detection of metallic impurities in pharmaceuticals, health products, biological products, cosmetics, gifts, packaging, papers, and so on.
Features:
Stable and high sensitivity & precision
Mature phase adjustment technology, avoiding shortcomings like no phase of LC analog circuit, low stability, without products suppression function and machine aging caused by time and temperature
Auto-setting function
Fast learn product character automatically and finish the Auto-setting process.
New Function:
-Phase tracking function with can maintain the stable high-sensitivity detection ability
-Product tracking function, which can do adjustment and compensation according to the changes of the product effect automatically
– Auto-balanced calibration function, which can ensure the service life of the machine
User-friendly function
Automatic rewind function, dispense with handling large product;
100 products can be restored in database;
USB and Ethernet interfaces are available;
LCD, Chinese-English touch screen, easy operation;
International languages customized;
Easy to be cleaned
IP65 Dust and Waterproof Wash-down Construction customized available
Main Parameters:
Detecting width
400, 500 mm (can be customized)
Detecting height
80, 100, 120, 150, 200, 250, 300, 350 mm (can be customized)
Detecting sensitivity
Fe 0.8mm-3.0mm, Non-Fe 1.2mm- 4.0mm
Stainless Steel 1.5mm- 5.0mm
Display Screen
4.3inch, 7inch (optional)
Sensitivity adjustment
100 level adjustment
Detecting adjustment
Intelligent adjustable
Belt Speed
20m /min (or specified)
Alarm mode
The buzzer alarm, the motor automatically stop
Power
AC22V,50Hz (customized)
Model selection function table:
Model
Function
NG-706B
(4.3 inch screen
Basic model)
NG-706B1
(4.3 inch screen
Functional model)
NG-706A
(7 inch screen
Functional model)
NG-706A1
(7 inch screen
Versatile model)
Frequency Adjustable
√
√
√
√
Phase Adjustable
√
√
√
√
Gain Adjustable
√
√
√
√
Threshold Adjustable
√
√
√
√
Sound Adjustable
√
√
√
√
Alarm Time Adjustable
√
√
√
√
Storage Quantity
(Kinds of Product )
3/12
3/12
12
15/100
Belt Run/Stop when
Alarm
√
√
√
√
Auto Learning
×
√
√
√
Counter
×
√
√
√
No Metal Alarm
(customization function)
×
×
×
√
Belt Right and Left
Running
×
×
×
√
Belt Rewinding when
Alarm
×
×
×
√
Automatic Elimination
×
×
√
√
Lampstandard
×
×
√
√
