Industrial Hot Air Anti Explosion Drying Oven, Battery Shock Anti Explosion Oven
Model
NG-FB
MOQ
1 Set
Lead Time
3-15 Working Days
Country of Origin
China
Package
Standard Export Wooden Box
OEM & ODM
Support
描述
用户评论 (0)
描述
Summary:
Anti Explosion Drying Oven can provide a stable test space for pre-heating, drying, changes about physics and chemistry testing . The baking oven supply precision temperature controller with high stability of platinum resistance to temperature that makes temperature well-distribution.
Horizontal hot air cycle: suitable for baking of sheet products, such as metal, plastic film, film screen printing, leather processing, etc.
Upper and lower hot air cycle: suitable for baking of smaller products, such as baked paint for toys and hardware parts.
Structure:
Material of inner box: stainless steel plate
Material: cold rolled steel baking paint
Insulation material: high efficient compressed glass wool
Insulation device: no fuse switch, over-temperature protection switch, fuse
Safety device: over-temperature alarm, overload protection, etc
Exhaust duct: vane design can adjust the air volume
Control formation: when the temperature reaches the set temperature, the timer will be automatically turned on. When the time arrives, the heating power will be cut off and the buzzer will prompt
Supply air circulation system: counter flow supply air circulation system
Control system: temperature to time, time to stop, buzzer stop
Air supply system:
Forced convection air supply cycle. The air source is driven by the circulation motor to drive the wind wheel through the electric heater, and the hot air is sent to the oven from the duct
After use, the hot air is drawn into the duct and becomes the air source for re-heating, thus reducing the energy loss and ensuring the temperature in the box
Degree of uniformity. When the door is disturbed by the opening and closing actions, the air supply circulation system can quickly recover the operating temperature.
Dedicated long shaft motor with high temperature resistance and power of 1HP 50Hz
The fan is a multi-blade turbine with high strength and is equipped with an adjustable air guide plate to make the wind path run more smoothly
Main Specifications:
Inner chamber size
400×400×450mm (or customized)
Outer size
650×920×530mm (or based on inner size)
Temperature range
RT~200℃
Temperature stability
±1.0℃
Temperature uniformity
±2℃
Temperature rising speed
5℃/min
Temperature controller
Programmable rising
