Summary:
Direct readings, with temperature compensation, and Solution compensation, more humanized operation, suitable for on site operations. For density determination of rubber, plastic, wire and cable, electrical appliances, sports equipment, tires, glass products, hard alloy, powder metallurgy, magnetic materials, seals, ceramics, sponge, EVA materials, foam materials, alloys, friction materials, New materials, battery materials.
Standards:
ASTM D792, ASTM D297, GB / T1033, GB / T2951, GB / T3850, GB / T533, HG4-1468,
JIS K6268, ISO 2505, ISO 1183, ISO2781, ASTMD297-93, DIN 53479, D618, D891,
ASTM D792 -00, JISK6530, ASTM D792-00, JISK6530
Features:
1.Direct reading density and volume of solid, particles and floating body in any shape, which density> 1 or <1
With temperature compensation setting, and solution compensation setting function, more humane operation
The density measurement station in one injection molding, easy and fast to install, long life-time.
Use corrosion-resistant large error integrally molded sink design to reduce the buoyancy of the hanging bar line caused, but also easy to test a relatively large massive objects
With the lower and upper limit function, can determine the proportion qualified or not, equipped with a buzzer system.
Built-in battery, with configuration windshield, more suitable for field testing.
7. Configuration special wind dust cover, combination convenient, strong and durable
8. Including RS – 232 – c communication interface, convenient connection PC and printers, can choose and buy QL – P printers print quickly measuring data
Models & Specifications
Model
DZ-MK200
DZ-MK300
DZ-MK500
DZ-MK120
Max capacity
220g
300g
500g
120g
Test precision
0.001g
0.001g
0.001g
0.0001g
Density precision
0.001 g/cm3
0.001 g/cm3
0.001 g/cm3
0.0001 g/cm3
Model
DZ-MK200A
DZ-MK300A
DZ-MK500A
DZ-MK120A
Density precision
0.0001 g/cm3
0.0001 g/cm3
0.0001 g/cm3
0.00001 g/cm3
Response time
5 seconds
Temperature compensation:
Solution temperature can set to 0~49°C
Solution compensation:
Solution can set to 19.999
Mix proportion:
Set two kinds of mixture mixing ratio function
Solid test steps:
1, Put the sample on the test table, press “MEMORY” key.
2, Put the sample in the nasket in the water, press “MEMORY” key to display density fastly.
