Application:
Government departments: including courts, subways, high-speed rail, prisons, detention centers, labor camps, drug treatment centers, and public security bureaus.
Public places: including schools, gymnasiums, entertainment venues (disc halls, dance halls, etc.), airports, railway stations, bus stations, ports, exhibition halls, museums, banks, oil depots, power stations, etc.
Advantages:
Spellman brand generator from the USA.
Hamamatsu brand detector from Japan.
Interroll brand Roller from German.
Protective cover on lead curtain to avoid lead pollution.
Sound and light alarm.
Local network supported.
Features:
* Original Hamamatsu detectors, image quality, Omron electrical components.Enhance the
overall quality
* Global leading parameters: the inspection report issued by the Ministry of Public
Security, shows that each parameter is ahead of other products, more details in the inspection report.
* Energy-saving design: The machine can sense objects automatically,if there is luggage
on the machine will be operating, if there is no luggage,it’ll be quiet. (Optional)
* A key shutdown control: simply rotate the key when clicking shutdown,safe shutdown
automaticly ,reduce equipment failure.
* Environmental-friendly Design: lead shade with protective film, prevent lead from hand
contact, avoid lead pollution.
* Dynamic screen switching: when it is stationary screen it can be switched and when it
is dynamic it also can switch freely.
Technical Specifications:
X-ray Generator
Ray Beam direction
Bottom-illuminated
Tube current
0.4~0.5mA（adjustable）
Tube voltage
100-160 kV（adjustable）
Ray beam divergence angle
60°
The cooling / work cycle
Sealed oil cooling / 100％
Image Processing System
X-ray sensor
L-shaped photodiode array detector (C), 24bit depth
Monitor
high resolution 19 inch LCD SamSung monitor
Color image display
24-bit true color display
Edge Enhancement
the outline of objects will be more clear
Super Image Enhancement
the details of the image are more clear
High penetration display
improve image contrast in dark areas, so the difficult penetrating area will be more clear
Low penetration display
improve image contrast in dark areas, so the difficult penetrating area will be more clear
Magnifier
local amplification function
Brighten / darken
Increase/ decrease image brightness
Image pull back / front pull
Show the top 20 images, and the current image can be any image processing
Image Restoration
Restored to its original state
Image Storage
Real-time save any image, any image can be processed arbitrarily ,continuous work to save
Environmental conditions
Operating temperature / humidity
0℃～45℃／20%～95% (No condensation)
Storage temperature / humidity
-20℃～60℃／20%～95% (No condensation)
Operating Voltage
220VAC(±10%) 50±3Hz
Power consumption
1.0KW（maximum）
Noise level
<55dB （A）
Technical Standards
Technical Parameters
The channel size
500（W）×300（H）mm
Conveyor speed
0.22m/s
Load
20 kg
Resolution
0.0787 mm
Penetration
≥40 mm steel plate
Monitor
Samsung 19in LCD Monitor
Storage
500G hard drive to save any image in real time, can store more than 100,000 and
can make any image processing, and continuous work to save.
Noise
< 55dB(A)
Operating system
windowsXP
Film Safety
Safety to the ISO1600
Leaking radiation dose rate
Safety to the ISO1600
Dimensions
Away from any device outer surface of 5cm, the ray irradiation leak rate should
be < 0.05µGy/H
NW / GW
290 kg / 360 kg
Applications
Customs, port, prosecutors, prisons, railway stations, courts and other security units.
