QRF630 6 Zones SMT Reflow Oven solder welding with cabinet
The QRF630 infrared benchtop reflow oven uses the PID temperature control system and rapid infrared heating technology controlling, 6 zones ,Length of heating zone 1060mm ,so the temperature is being kept very accurate and evenly distributed.
Description
Inquiry
Description
QiHe QRF630 infrared benchtop reflow oven 6 zones ,Length of heating zone 1060mm ,power 3kw,
The QRF630 the PID temperature control system and rapid infrared heating technology controlling, so the temperature is being kept very accurate and evenly distributed. The whole soldering process can be completed automatically and it is very easy to use. It is suitable for the board has chips and output is larger or the welding quality requirements are better.Designed with Multi-temperature curve choose.Four zones special temperature control mode more stable and precise.High quality thermocouple porcelain bead protect.Full-color HMI human-computer interface(touch screen).Super anti-temperature fan.Liner hearth use industrial grade anti high temperature and corrosion panel paint.PID microcomputer global temperature control system. High efficiency and energy saving finned heating tube.High temperature fan.Built in analog governor.
ModelQRF630Heat zone numbers6 zones(Up3, Down3)Heat methodHot windCooling zone numbersTwo natural air coolingLength of heating zone1060mmWidth of net belt300mmPCB size280mmHeight of net belt900±20mmTransport speed of net belt160~1350mm/min(Analog quantity adjusting)Transport direction of net beltLeft to right( right to left)Starting power9KWWorking power3KWInput supply powerThree-phase five-wire 380±10% 50HZHeat up timeAbout 20 minsTime of passing through the machine3.5 to 5.5 minsRange of temperature controlIndoor temperature to 400 degreesMethod of temperature controlPID close cycle controlNet weight215kgOutline size2100x680x1200mm
