QM81 8 heads,80 feeder slots,Panasonic servo,ball screw,with rail,Fully Automatic Chip Mounter,
Description
Inquiry
Description
The QM81 SMT pick and place machine (Chip mounter)has been upgraded from the QM61 SMT Assembly series and incorporated customer feedback.Not only increased more mounting heads but also more feeder slots .QM81 pnp machine even improved the hardware like flying shot recognition camera,the DSP digital driver,the ball grinding screw,the master computer .Upgraded the software functional such as the component library ,the visual surveillance,the safety alerts,the fault previously warning .QM81 pick&place machine can easily handling special-shaped components, BGA, 0201 inch package.X Y axis adopts bigger Panasonic servo motor, speed of up to 16000 components per hour (CPH),without sacrificing the CPH rate with high troque to achieve never lost step accuracy ＜ 0.001mm.
ModelQM81Max applicable PCB size450*350mmMax xy moving range720*760mmMax z moving range20 or 32mmPlacement head quantity8Max mounting capabilityVision on: 13000pcs/hVision off: 16000pcs/hFeeder slots capability80 (YAMAHA Feeder is available)Applicable component Smallest size:0201 inchLargest size:22*22mmMax Height15mmVisual camera Flying HD CCD cameraPower supply220VNet Weight1015kgMachine Dimension1310*1140*1390mmPacking size3.52 CBM
Read more: QM81 SMT pick and place machine 8heads 80slots Fully Automatic Chip mounter SMT Assembly
